A1000G33NC

Material Material:

PA6

Specification Specification:

33% glass fiber reinforced

Color Color:

Natural color, providing custom dyeing service

Certification Certification:

RoHS、REACH

Package Package:

25kg

Property Property:

Having excellent properties of high stiffness, strength and heat resistance

1. 物性標準 Materials Standard:

檢測項目 Property 測試方法
Test Method
單位
Unit
數值
Vaule
機械性質 Mechanical Properties
抗張強度 Tensile Strength ASTM D638 Kg/cm2 1700
延伸率 Elongation at Break ASTM D638 % < 5
彎曲強度 Flexural Strength ASTM D790 kg/cm2 2800
彎曲彈性模數 Flexural Modulus ASTM D790 kg/cm2 85000
衝擊強度 IZOD Impact, Notched 1/8" 23°C
IZOD Impact, Notched 1/8" -30°C
ASTM D256 kg-cm/cm 13
硬度 Hardness Shore D
Hardness Rockwell R Scale
ASTM D2240
ASTM D785
- 120
熱特性 Thermal
熱變形溫度 Heat Deflection Temperature
(18.6kg/cm2 )
ASTM D648 °C 200
其它 Other
收縮率 Shrinkage ASTM D955 % 0.2~0.6
熔融指數 Melt Index ASTM D1238 g/10min -
比重 Specific Gravity ASTM D792 - 1.38
灰份 Ash Content ASTM D482 % 33
含水率 Equilibrium Moisture Content ASTM D570 % < 0.3
耐燃性 Flammability UL 94 1.6mm -

2.成形條件 Molding Condition:

乾燥條件 Drying 料管溫度 Melt Temp 射出壓力 Inject Press.
80~100°C*4HR 235~260°C 20kg/cm2

附註:測試條件: 23℃, 50%RH, 24小時。以上數據會隨使用條件不同而有所改變,故此數據僅供參考。
Note:Test Conditions : 23℃, 50%RH, 24 hours.The data sheet is for your reference. And the data above will vary as the actual using condition changes.

Applications

Scooters fairing cover, Kitchenware and utensils, Lighting. Hardware, Mechanical parts, Leisure sports equipment. Hand tool, Bicycle brake parts, Fishing tackle reel, Scroll door, Home appliance parts, Motor housing, Hairdryer nozzle.

A1000G45NC

Material Material:

PA6

Specification Specification:

45% glass fiber reinforced

Color Color:

Natural color, providing custom dyeing service

Certification Certification:

RoHS、REACH

Package Package:

25kg

Property Property:

Meet the requirements of higher stiffness, strength and heat distortion temperature

1. 物性標準 Materials Standard:

檢測項目 Property 測試方法
Test Method
單位
Unit
數值
Vaule
機械性質 Mechanical Properties
抗張強度 Tensile Strength ASTM D638 Kg/cm2 1900
延伸率 Elongation at Break ASTM D638 % < 5
彎曲強度 Flexural Strength ASTM D790 kg/cm2 3000
彎曲彈性模數 Flexural Modulus ASTM D790 kg/cm2 110000
衝擊強度 IZOD Impact, Notched 1/8" 23°C
IZOD Impact, Notched 1/8" -30°C
ASTM D256 kg-cm/cm 16
硬度 Hardness Shore D
Hardness Rockwell R Scale
ASTM D2240
ASTM D785
- 120
熱特性 Thermal
熱變形溫度 Heat Deflection Temperature
(18.6kg/cm2 )
ASTM D648 °C 210
其它 Other
收縮率 Shrinkage ASTM D955 % 0.1~0.4
熔融指數 Melt Index ASTM D1238 g/10min -
比重 Specific Gravity ASTM D792 - 1.47
灰份 Ash Content ASTM D482 % 45
含水率 Equilibrium Moisture Content ASTM D570 % < 0.3
耐燃性 Flammability UL 94 1.6mm -

2.成形條件 Molding Condition:

乾燥條件 Drying 料管溫度 Melt Temp 射出壓力 Inject Press.
80~100°C*4HR 235~260°C 20kg/cm2

附註:測試條件: 23℃, 50%RH, 24小時。以上數據會隨使用條件不同而有所改變,故此數據僅供參考。
Note:Test Conditions : 23℃, 50%RH, 24 hours.The data sheet is for your reference. And the data above will vary as the actual using condition changes.

Applications

Hardware, Mechanical parts
Sports equipment, Power tool housing, Hand tool, Bicycle brake parts, Fishing tackle reel, Scroll door, Home appliance parts, Motor housing, Hairdryer nozzle.

A2000G33SD

Material Material:

PA6

Specification Specification:

33% glass fiber reinforced

Color Color:

White, providing custom dyeing services

Certification Certification:

RoHS、REACH、GRS(Global Recycle Standard)

Package Package:

25kg

Property Property:

Having excellent properties of high stiffness, strength and heat resistance

1. 物性標準 Materials Standard:

檢測項目 Property 測試方法
Test Method
單位
Unit
數值
Vaule
機械性質 Mechanical Properties
抗張強度 Tensile Strength ASTM D638 Kg/cm2 1500
延伸率 Elongation at Break ASTM D638 % < 5
彎曲強度 Flexural Strength ASTM D790 kg/cm2 2400
彎曲彈性模數 Flexural Modulus ASTM D790 kg/cm2 82000
衝擊強度 IZOD Impact, Notched 1/8" 23°C
IZOD Impact, Notched 1/8" -30°C
ASTM D256 kg-cm/cm 9
硬度 Hardness Shore D
Hardness Rockwell R Scale
ASTM D2240
ASTM D785
- 120
熱特性 Thermal
熱變形溫度 Heat Deflection Temperature
(18.6kg/cm2 )
ASTM D648 °C 200
其它 Other
收縮率 Shrinkage ASTM D955 % 0.2~0.6
熔融指數 Melt Index ASTM D1238 g/10min -
比重 Specific Gravity ASTM D792 - 1.38
灰份 Ash Content ASTM D482 % 33
含水率 Equilibrium Moisture Content ASTM D570 % < 0.3
耐燃性 Flammability UL 94 1.6mm -

2.成形條件 Molding Condition:

乾燥條件 Drying 料管溫度 Melt Temp 射出壓力 Inject Press.
80~100°C*4HR 235~260°C 20kg/cm2

附註:測試條件: 23℃, 50%RH, 24小時。以上數據會隨使用條件不同而有所改變,故此數據僅供參考。
Note:Test Conditions : 23℃, 50%RH, 24 hours.The data sheet is for your reference. And the data above will vary as the actual using condition changes.

Applications

Sports equipment, Hand tool, Bicycle brake parts, Office desk & chair, Home appliance parts, Motor housing, Hairdryer nozzle.

A5501G15FD

Material Material:

PA6

Specification Specification:

15% glass fiber reinforced

Color Color:

Ultral white, providing custom dyeing services

Certification Certification:

RoHS、REACH、GRS(Global Recycle Standard)

Package Package:

25kg

Property Property:

Enhances stiffness, strength and heat resistance

1. 物性標準 Materials Standard:

檢測項目 Property 測試方法
Test Method
單位
Unit
數值
Vaule
機械性質 Mechanical Properties
抗張強度 Tensile Strength ASTM D638 Kg/cm2 900
延伸率 Elongation at Break ASTM D638 % < 5
彎曲強度 Flexural Strength ASTM D790 kg/cm2 1600
彎曲彈性模數 Flexural Modulus ASTM D790 kg/cm2 45000
衝擊強度 IZOD Impact, Notched 1/8" 23°C
IZOD Impact, Notched 1/8" -30°C
ASTM D256 kg-cm/cm 5
硬度 Hardness Shore D
Hardness Rockwell R Scale
ASTM D2240
ASTM D785
- 115
熱特性 Thermal
熱變形溫度 Heat Deflection Temperature
(18.6kg/cm2 )
ASTM D648 °C 180
其它 Other
收縮率 Shrinkage ASTM D955 % 0.3~0.7
熔融指數 Melt Index ASTM D1238 g/10min -
比重 Specific Gravity ASTM D792 - 1.25
灰份 Ash Content ASTM D482 % 15
含水率 Equilibrium Moisture Content ASTM D570 % < 0.3
耐燃性 Flammability UL 94 1.6mm -

2.成形條件 Molding Condition:

乾燥條件 Drying 料管溫度 Melt Temp 射出壓力 Inject Press.
80~100°C*4HR 235~260°C 20kg/cm2

附註:測試條件: 23℃, 50%RH, 24小時。以上數據會隨使用條件不同而有所改變,故此數據僅供參考。
Note:Test Conditions : 23℃, 50%RH, 24 hours.The data sheet is for your reference. And the data above will vary as the actual using condition changes.

A3000G15BK

Material Material:

PA6

Specification Specification:

15% glass fiber reinforced

Color Color:

Black

Certification Certification:

RoHS、REACH、GRS(Global Recycle Standard)

Package Package:

25kg

Property Property:

Enhances hardness, strength and heat resistance

1. 物性標準 Materials Standard:

檢測項目 Property 測試方法
Test Method
單位
Unit
數值
Vaule
機械性質 Mechanical Properties
抗張強度 Tensile Strength ASTM D638 Kg/cm2 800
延伸率 Elongation at Break ASTM D638 % < 5
彎曲強度 Flexural Strength ASTM D790 kg/cm2 1500
彎曲彈性模數 Flexural Modulus ASTM D790 kg/cm2 40000
衝擊強度 IZOD Impact, Notched 1/8" 23°C
IZOD Impact, Notched 1/8" -30°C
ASTM D256 kg-cm/cm 5
硬度 Hardness Shore D
Hardness Rockwell R Scale
ASTM D2240
ASTM D785
- 115
熱特性 Thermal
熱變形溫度 Heat Deflection Temperature
(18.6kg/cm2 )
ASTM D648 °C 180
其它 Other
收縮率 Shrinkage ASTM D955 % 0.3~0.7
熔融指數 Melt Index ASTM D1238 g/10min -
比重 Specific Gravity ASTM D792 - 1.25
灰份 Ash Content ASTM D482 % 15
含水率 Equilibrium Moisture Content ASTM D570 % < 0.3
耐燃性 Flammability UL 94 1.6mm -

2.成形條件 Molding Condition:

乾燥條件 Drying 料管溫度 Melt Temp 射出壓力 Inject Press.
80~100°C*4HR 235~260°C 20kg/cm2

附註:測試條件: 23℃, 50%RH, 24小時。以上數據會隨使用條件不同而有所改變,故此數據僅供參考。
Note:Test Conditions : 23℃, 50%RH, 24 hours.The data sheet is for your reference. And the data above will vary as the actual using condition changes.

Applications

Sports Equipment, Hand tool, Bicycle brake parts, Home qppliance parts, Motor housing, Hairdryer nozzle.

A3000G30BK

Material Material:

PA6

Specification Specification:

30% glass fiber reinforced

Color Color:

Black

Certification Certification:

RoHS、REACH、GRS(Global Recycle Standard)

Package Package:

25kg

Property Property:

Having excellent properties of high stiffness, strength and heat resistance

1. 物性標準 Materials Standard:

檢測項目 Property 測試方法
Test Method
單位
Unit
數值
Vaule
機械性質 Mechanical Properties
抗張強度 Tensile Strength ASTM D638 Kg/cm2 1300
延伸率 Elongation at Break ASTM D638 % < 5
彎曲強度 Flexural Strength ASTM D790 kg/cm2 2100
彎曲彈性模數 Flexural Modulus ASTM D790 kg/cm2 73000
衝擊強度 IZOD Impact, Notched 1/8" 23°C
IZOD Impact, Notched 1/8" -30°C
ASTM D256 kg-cm/cm 8
硬度 Hardness Shore D
Hardness Rockwell R Scale
ASTM D2240
ASTM D785
- 120
熱特性 Thermal
熱變形溫度 Heat Deflection Temperature
(18.6kg/cm2 )
ASTM D648 °C 200
其它 Other
收縮率 Shrinkage ASTM D955 % 0.2~0.6
熔融指數 Melt Index ASTM D1238 g/10min -
比重 Specific Gravity ASTM D792 - 1.36
灰份 Ash Content ASTM D482 % 30
含水率 Equilibrium Moisture Content ASTM D570 % < 0.3
耐燃性 Flammability UL 94 1.6mm -

2.成形條件 Molding Condition:

乾燥條件 Drying 料管溫度 Melt Temp 射出壓力 Inject Press.
80~100°C*4HR 235~260°C 20kg/cm2

附註:測試條件: 23℃, 50%RH, 24小時。以上數據會隨使用條件不同而有所改變,故此數據僅供參考。
Note:Test Conditions : 23℃, 50%RH, 24 hours.The data sheet is for your reference. And the data above will vary as the actual using condition changes.

Applications

Automobiles interior handle, Automobiles gear assembly.
Hardware, Mechanical parts, Hand tool, Bicycle brake parts, Fishing tackle reel, Scroll door, Hairdryer nozzle.

A3000G35BK

Material Material:

PA6

Specification Specification:

35% glass fiber reinforced

Color Color:

Black

Certification Certification:

RoHS、REACH、GRS(Global Recycle Standard)

Package Package:

25kg

Property Property:

With excellent high stiffness, strength, heat resistance and dimensional stability

1. 物性標準 Materials Standard:

檢測項目 Property 測試方法
Test Method
單位
Unit
數值
Vaule
機械性質 Mechanical Properties
抗張強度 Tensile Strength ASTM D638 Kg/cm2 1550
延伸率 Elongation at Break ASTM D638 % < 5
彎曲強度 Flexural Strength ASTM D790 kg/cm2 2300
彎曲彈性模數 Flexural Modulus ASTM D790 kg/cm2 77000
衝擊強度 IZOD Impact, Notched 1/8" 23°C
IZOD Impact, Notched 1/8" -30°C
ASTM D256 kg-cm/cm 9
硬度 Hardness Shore D
Hardness Rockwell R Scale
ASTM D2240
ASTM D785
- 120
熱特性 Thermal
熱變形溫度 Heat Deflection Temperature
(18.6kg/cm2 )
ASTM D648 °C 200
其它 Other
收縮率 Shrinkage ASTM D955 % 0.2~0.6
熔融指數 Melt Index ASTM D1238 g/10min -
比重 Specific Gravity ASTM D792 - 1.40
灰份 Ash Content ASTM D482 % 35
含水率 Equilibrium Moisture Content ASTM D570 % < 0.3
耐燃性 Flammability UL 94 1.6mm -

2.成形條件 Molding Condition:

乾燥條件 Drying 料管溫度 Melt Temp 射出壓力 Inject Press.
80~100°C*4HR 235~260°C 20kg/cm2

附註:測試條件: 23℃, 50%RH, 24小時。以上數據會隨使用條件不同而有所改變,故此數據僅供參考。
Note:Test Conditions : 23℃, 50%RH, 24 hours.The data sheet is for your reference. And the data above will vary as the actual using condition changes.

A2000G40BK

Material Material:

PA6

Specification Specification:

40% glass fiber reinforced

Color Color:

Black

Certification Certification:

RoHS、REACH、GRS(Global Recycle Standard)

Package Package:

25kg

Property Property:

With the properties of high stiffness, high strength and heat resistance

1. 物性標準 Materials Standard:

檢測項目 Property 測試方法
Test Method
單位
Unit
數值
Vaule
機械性質 Mechanical Properties
抗張強度 Tensile Strength ASTM D638 Kg/cm2 1700
延伸率 Elongation at Break ASTM D638 % < 5
彎曲強度 Flexural Strength ASTM D790 kg/cm2 3100
彎曲彈性模數 Flexural Modulus ASTM D790 kg/cm2 100000
衝擊強度 IZOD Impact, Notched 1/8" 23°C
IZOD Impact, Notched 1/8" -30°C
ASTM D256 kg-cm/cm 14
硬度 Hardness Shore D
Hardness Rockwell R Scale
ASTM D2240
ASTM D785
- 120
熱特性 Thermal
熱變形溫度 Heat Deflection Temperature
(18.6kg/cm2 )
ASTM D648 °C 210
其它 Other
收縮率 Shrinkage ASTM D955 % 0.1~0.4
熔融指數 Melt Index ASTM D1238 g/10min -
比重 Specific Gravity ASTM D792 - 1.44
灰份 Ash Content ASTM D482 % 40
含水率 Equilibrium Moisture Content ASTM D570 % < 0.3
耐燃性 Flammability UL 94 1.6mm -

2.成形條件 Molding Condition:

乾燥條件 Drying 料管溫度 Melt Temp 射出壓力 Inject Press.
80~100°C*4HR 235~260°C 20kg/cm2

附註:測試條件: 23℃, 50%RH, 24小時。以上數據會隨使用條件不同而有所改變,故此數據僅供參考。
Note:Test Conditions : 23℃, 50%RH, 24 hours.The data sheet is for your reference. And the data above will vary as the actual using condition changes.

Applications

Sports equipment, Fishing tackle reel, Home appliance parts, Motor housing, Hairdryer nozzle.

A3000G45BK

Material Material:

PA6

Specification Specification:

45% glass fiber reinforced

Color Color:

Black

Certification Certification:

RoHS、REACH、GRS(Global Recycle Standard)

Package Package:

25kg

Property Property:

With the properties of high stiffness, high strength and heat resistance

1. 物性標準 Materials Standard:

檢測項目 Property 測試方法
Test Method
單位
Unit
數值
Vaule
機械性質 Mechanical Properties
抗張強度 Tensile Strength ASTM D638 Kg/cm2 1700
延伸率 Elongation at Break ASTM D638 % < 5
彎曲強度 Flexural Strength ASTM D790 kg/cm2 2900
彎曲彈性模數 Flexural Modulus ASTM D790 kg/cm2 110000
衝擊強度 IZOD Impact, Notched 1/8" 23°C
IZOD Impact, Notched 1/8" -30°C
ASTM D256 kg-cm/cm 10
硬度 Hardness Shore D
Hardness Rockwell R Scale
ASTM D2240
ASTM D785
- 120
熱特性 Thermal
熱變形溫度 Heat Deflection Temperature
(18.6kg/cm2 )
ASTM D648 °C 210
其它 Other
收縮率 Shrinkage ASTM D955 % 0.1~0.4
熔融指數 Melt Index ASTM D1238 g/10min -
比重 Specific Gravity ASTM D792 - 1.50
灰份 Ash Content ASTM D482 % 45
含水率 Equilibrium Moisture Content ASTM D570 % < 0.3
耐燃性 Flammability UL 94 1.6mm -

2.成形條件 Molding Condition:

乾燥條件 Drying 料管溫度 Melt Temp 射出壓力 Inject Press.
80~100°C*4HR 235~260°C 20kg/cm2

附註:測試條件: 23℃, 50%RH, 24小時。以上數據會隨使用條件不同而有所改變,故此數據僅供參考。
Note:Test Conditions : 23℃, 50%RH, 24 hours.The data sheet is for your reference. And the data above will vary as the actual using condition changes.

Applications

Sports equipment, Power tool housing, Hand tool, Bicycle brake parts, Fishing tackle reel, Scroll door, Office desk & chair, Home appliance parts, Motor housing, Hairdryer nozzle.

We uphold the values for the Common Good and contribute to a Circular Economy through the Recycling of Nylon Materials

0
