PA66

PA66

Glass Fiber Reinforced/Impact Modified

Glass fiber reinforced nylon for enhanced strength, stiffness and Low temperature impact resistance.

B3000GT15BKA2

Material Material：

PA66

Specification Specification：

Impact resistant 15% glass fiber reinforced

Color Color：

Black

Certification Certification：

RoHS、REACH、GRS(Global Recycle Standard)

Package Package：

25kg

Property Property：

Excellent high stiffness, strength and low temperature impact resistance

B3000GT15BKA2 Add to Inquriy Cart Download

1. 物性標準 Materials Standard：

檢測項目 Property 測試方法
Test Method 		單位
Unit 		數值
Vaule
機械性質 Mechanical Properties
抗張強度 Tensile Strength ASTM D638 Kg/cm2 600
延伸率 Elongation at Break ASTM D638 % < 5
彎曲強度 Flexural Strength ASTM D790 kg/cm2 1000
彎曲彈性模數 Flexural Modulus ASTM D790 kg/cm2 38000
衝擊強度 IZOD Impact, Notched 1/8" 23°C
IZOD Impact, Notched 1/8" -30°C 		ASTM D256 kg-cm/cm 9
硬度 Hardness Shore D
Hardness Rockwell R Scale 		ASTM D2240
ASTM D785 		-
115
熱特性 Thermal
熱變形溫度 Heat Deflection Temperature
(18.6kg/cm2 ) 		ASTM D648 °C 230
其它 Other
收縮率 Shrinkage ASTM D955 % 0.3~1.0
熔融指數 Melt Index ASTM D1238 g/10min -
比重 Specific Gravity ASTM D792 - 1.20
灰份 Ash Content ASTM D482 % 15
含水率 Equilibrium Moisture Content ASTM D570 % < 0.3
耐燃性 Flammability UL 94 1.6mm -

2.成形條件 Molding Condition：

乾燥條件 Drying 料管溫度 Melt Temp 射出壓力 Inject Press.
80~100°C*4HR 245~280°C 20kg/cm2

附註:測試條件: 23℃, 50%RH, 24小時。以上數據會隨使用條件不同而有所改變，故此數據僅供參考。
Note:Test Conditions : 23℃, 50%RH, 24 hours.The data sheet is for your reference. And the data above will vary as the actual using condition changes.

Applications

Bicycles - Bicycle Rack
Baby Strollers, Bicycle brake parts.
Snow shoe, Skates, Leisure sports equipment.
Power tool housing, Skate sole, Wheelchair wheel frame.

B2201GT30BKE1

Material Material：

PA66

Specification Specification：

Impact resistant 30% glass fiber reinforced

Color Color：

Black

Certification Certification：

RoHS、REACH、GRS(Global Recycle Standard)

Package Package：

25kg

Property Property：

Excellent high stiffness, strength and low temperature impact resistance

B2201GT30BKE1 Add to Inquriy Cart Download

1. 物性標準 Materials Standard：

檢測項目 Property 測試方法
Test Method 		單位
Unit 		數值
Vaule
機械性質 Mechanical Properties
抗張強度 Tensile Strength ASTM D638 Kg/cm2 1300
延伸率 Elongation at Break ASTM D638 % < 5
彎曲強度 Flexural Strength ASTM D790 kg/cm2 2050
彎曲彈性模數 Flexural Modulus ASTM D790 kg/cm2 70000
衝擊強度 IZOD Impact, Notched 1/8" 23°C
IZOD Impact, Notched 1/8" -30°C 		ASTM D256 kg-cm/cm 10
硬度 Hardness Shore D
Hardness Rockwell R Scale 		ASTM D2240
ASTM D785 		-
120
熱特性 Thermal
熱變形溫度 Heat Deflection Temperature
(18.6kg/cm2 ) 		ASTM D648 °C 245
其它 Other
收縮率 Shrinkage ASTM D955 % 0.3~0.8
熔融指數 Melt Index ASTM D1238 g/10min -
比重 Specific Gravity ASTM D792 - 1.33
灰份 Ash Content ASTM D482 % 30
含水率 Equilibrium Moisture Content ASTM D570 % < 0.3
耐燃性 Flammability UL 94 1.6mm -

2.成形條件 Molding Condition：

乾燥條件 Drying 料管溫度 Melt Temp 射出壓力 Inject Press.
80~100°C*4HR 245~280°C 20kg/cm2

附註:測試條件: 23℃, 50%RH, 24小時。以上數據會隨使用條件不同而有所改變，故此數據僅供參考。
Note:Test Conditions : 23℃, 50%RH, 24 hours.The data sheet is for your reference. And the data above will vary as the actual using condition changes.

Applications

Medical Equipment - Wheelchair Wheel
Baby Strollers, Bicycle brake parts.
Snow shoe, Skates, Lesinure sports equipment.
Power tool housing, Skate sole, Wheelchair wheel frame
