A2000G15BK

Material Material:

PA6

Specification Specification:

15% Glass Fiber Reinforced

Color Color:

Black

Certification Certification:

RoHS、REACH、GRS、UL

Package Package:

25kg

Property Property:

Enhanced hardness, strength and heat resistance

1. 物性標準 Materials Standard:

檢測項目 Property 測試方法
Test Method
單位
Unit
數值
Vaule
機械性質 Mechanical Properties
抗張強度 Tensile Strength ASTM D638 Kg/cm2 1100
延伸率 Elongation at Break ASTM D638 % < 5
彎曲強度 Flexural Strength ASTM D790 kg/cm2 1500
彎曲彈性模數 Flexural Modulus ASTM D790 kg/cm2 50000
衝擊強度 IZOD Impact, Notched 1/8" 23°C
IZOD Impact, Notched 1/8" -30°C
ASTM D256 kg-cm/cm 6
硬度 Hardness Shore D
Hardness Rockwell R Scale
ASTM D2240
ASTM D785
-
115
熱特性 Thermal
熱變形溫度 Heat Deflection Temperature
(18.6kg/cm2 )
ASTM D648 °C 180
其它 Other
收縮率 Shrinkage ASTM D955 % 0.2~0.6
熔融指數 Melt Index ASTM D1238 g/10min -
比重 Specific Gravity ASTM D792 - 1.24
灰份 Ash Content ASTM D482 % 15
含水率 Equilibrium Moisture Content ASTM D570 % < 0.3
耐燃性 Flammability UL 94 1.6mm -

2.成形條件 Molding Condition:

乾燥條件 Drying 料管溫度 Melt Temp 射出壓力 Inject Press.
80~100°C*4HR 235~260°C 20kg/cm2

附註:測試條件: 23℃, 50%RH, 24小時。以上數據會隨使用條件不同而有所改變,故此數據僅供參考。
Note:Test Conditions : 23℃, 50%RH, 24 hours.The data sheet is for your reference. And the data above will vary as the actual using condition changes.

Applications

Sporting equipment, Hand Tool, Bicycle brake parts, Home appliance parts, Motor housings, Hair dryer nozzle

A2000G33BK

Material Material:

PA6

Specification Specification:

33% Glass Fiber Reinforced

Color Color:

Black

Certification Certification:

RoHS、REACH、GRS、UL

Package Package:

25kg

Property Property:

Having excellent properties of high stiffness, strength and heat resistance

1. 物性標準 Materials Standard:

檢測項目 Property 測試方法
Test Method
單位
Unit
數值
Vaule
機械性質 Mechanical Properties
抗張強度 Tensile Strength ASTM D638 Kg/cm2 1500
延伸率 Elongation at Break ASTM D638 % < 5
彎曲強度 Flexural Strength ASTM D790 kg/cm2 2600
彎曲彈性模數 Flexural Modulus ASTM D790 kg/cm2 83500
衝擊強度 IZOD Impact, Notched 1/8" 23°C
IZOD Impact, Notched 1/8" -30°C
ASTM D256 kg-cm/cm 12
-
硬度 Hardness Shore D
Hardness Rockwell R Scale
ASTM D2240
ASTM D785
-
120
熱特性 Thermal
熱變形溫度 Heat Deflection Temperature
(18.6kg/cm2 )
ASTM D648 °C 200
其它 Other
收縮率 Shrinkage ASTM D955 % 0.2~0.6
熔融指數 Melt Index ASTM D1238 g/10min -
比重 Specific Gravity ASTM D792 - 1.38
灰份 Ash Content ASTM D482 % 33
含水率 Equilibrium Moisture Content ASTM D570 % < 0.3
耐燃性 Flammability UL 94 1.6mm -

2.成形條件 Molding Condition:

乾燥條件 Drying 料管溫度 Melt Temp 射出壓力 Inject Press.
80~100°C*4HR 235~260°C 20kg/cm2

附註:測試條件: 23℃, 50%RH, 24小時。以上數據會隨使用條件不同而有所改變,故此數據僅供參考。
Note:Test Conditions : 23℃, 50%RH, 24 hours.The data sheet is for your reference. And the data above will vary as the actual using condition changes.

Applications

Sports equipment, Hand tools, Bicycle brake parts, Office desk & chair, Home appliance parts, Motor housings, Hair dryer nozzle

A2000G45BK

Material Material:

PA6

Specification Specification:

45% Glass Fiber Reinforced

Color Color:

Black

Certification Certification:

RoHS、REACH、GRS、UL

Package Package:

25kg

Property Property:

It has the characteristics of high rigidity, high strength and heat resistance

1. 物性標準 Materials Standard:

檢測項目 Property 測試方法
Test Method
單位
Unit
數值
Vaule
機械性質 Mechanical Properties
抗張強度 Tensile Strength ASTM D638 Kg/cm2 1950
延伸率 Elongation at Break ASTM D638 % < 5
彎曲強度 Flexural Strength ASTM D790 kg/cm2 3250
彎曲彈性模數 Flexural Modulus ASTM D790 kg/cm2 115000
衝擊強度 IZOD Impact, Notched 1/8" 23°C
IZOD Impact, Notched 1/8" -30°C
ASTM D256 kg-cm/cm 16
硬度 Hardness Shore D
Hardness Rockwell R Scale
ASTM D2240
ASTM D785
-
120
熱特性 Thermal
熱變形溫度 Heat Deflection Temperature
(18.6kg/cm2 )
ASTM D648 °C 210
其它 Other
收縮率 Shrinkage ASTM D955 % 0.1~0.4
熔融指數 Melt Index ASTM D1238 g/10min -
比重 Specific Gravity ASTM D792 - 1.50
灰份 Ash Content ASTM D482 % 45
含水率 Equilibrium Moisture Content ASTM D570 % < 0.3
耐燃性 Flammability UL 94 1.6mm -

2.成形條件 Molding Condition:

乾燥條件 Drying 料管溫度 Melt Temp 射出壓力 Inject Press.
80~100°C*4HR 235~260°C 20kg/cm2

附註:測試條件: 23℃, 50%RH, 24小時。以上數據會隨使用條件不同而有所改變,故此數據僅供參考。
Note:Test Conditions : 23℃, 50%RH, 24 hours.The data sheet is for your reference. And the data above will vary as the actual using condition changes.

Applications

Sports Equipment, Pneumatic Tool Housing, Hand tool, Bicycle brake parts, Fishing tackle reels, Scroll doors, Office desks and chairs, Home appliance parts, Motor housings, Hair dryer nozzle

A2000G50BK

Material Material:

PA6

Specification Specification:

50% Glass Fiber Reinforced

Color Color:

Black

Certification Certification:

RoHS、REACH、GRS、UL

Package Package:

25kg

Property Property:

More excellent properties such as high rigidity and strength, heat resistance and dimensional stability

1. 物性標準 Materials Standard:

檢測項目 Property 測試方法
Test Method
單位
Unit
數值
Vaule
機械性質 Mechanical Properties
抗張強度 Tensile Strength ASTM D638 Kg/cm2 2100
延伸率 Elongation at Break ASTM D638 % < 5
彎曲強度 Flexural Strength ASTM D790 kg/cm2 3300
彎曲彈性模數 Flexural Modulus ASTM D790 kg/cm2 117000
衝擊強度 IZOD Impact, Notched 1/8" 23°C
IZOD Impact, Notched 1/8" -30°C
ASTM D256 kg-cm/cm 18
-
硬度 Hardness Shore D
Hardness Rockwell R Scale
ASTM D2240
ASTM D785
- -
120
熱特性 Thermal
熱變形溫度 Heat Deflection Temperature
(18.6kg/cm2 )
ASTM D648 °C 210
其它 Other
收縮率 Shrinkage ASTM D955 % 0.1~0.4
熔融指數 Melt Index ASTM D1238 g/10min -
比重 Specific Gravity ASTM D792 - 1.55
灰份 Ash Content ASTM D482 % 50
含水率 Equilibrium Moisture Content ASTM D570 % < 0.3
耐燃性 Flammability UL 94 1.6mm -

2.成形條件 Molding Condition:

乾燥條件 Drying 料管溫度 Melt Temp 射出壓力 Inject Press.
80~100°C*4HR 235~260°C 20kg/cm2

附註:測試條件: 23℃, 50%RH, 24小時。以上數據會隨使用條件不同而有所改變,故此數據僅供參考。
Note:Test Conditions : 23℃, 50%RH, 24 hours.The data sheet is for your reference. And the data above will vary as the actual using condition changes.

Applications

Sports Equipment, Pneumatic Tool Housing, Hand tool, Bicycle brake parts, Fishing tackle reels, Scroll doors, Office desks and chairs, Home appliance parts, Motor housings, Hair dryer nozzle
