C3000TBKA3

Material Material:

PA6/66

Specification Specification:

Low Temperature Impact Resistance

Color Color:

Black

Certification Certification:

RoHS、REACH、GRS(Global Recycle Standard)

Package Package:

25kg

Property Property:

Excellent ultra high toughness and low temperature impact resistance

1. 物性標準 Materials Standard:

檢測項目 Property 測試方法
Test Method
單位
Unit
數值
Vaule
機械性質 Mechanical Properties
抗張強度 Tensile Strength ASTM D638 Kg/cm2 430
延伸率 Elongation at Break ASTM D638 % > 80
彎曲強度 Flexural Strength ASTM D790 kg/cm2 700
彎曲彈性模數 Flexural Modulus ASTM D790 kg/cm2 17000
衝擊強度 IZOD Impact, Notched 1/8" 23°C
IZOD Impact, Notched 1/8" -30°C
ASTM D256 kg-cm/cm > 85
20
硬度 Hardness Shore D
Hardness Rockwell R Scale
ASTM D2240
ASTM D785
- 72
熱特性 Thermal
熱變形溫度 Heat Deflection Temperature
(18.6kg/cm2 )
ASTM D648 °C 50
其它 Other
收縮率 Shrinkage ASTM D955 % 1.6~2.0
熔融指數 Melt Index ASTM D1238 g/10min > 4
比重 Specific Gravity ASTM D792 - 1.07
灰份 Ash Content ASTM D482 % -
含水率 Equilibrium Moisture Content ASTM D570 % < 0.3
耐燃性 Flammability UL 94 1.6mm -

2.成形條件 Molding Condition:

乾燥條件 Drying 料管溫度 Melt Temp 射出壓力 Inject Press.
80~100°C*4HR 245~280°C 20kg/cm2

附註:測試條件: 23℃, 50%RH, 24小時。以上數據會隨使用條件不同而有所改變,故此數據僅供參考。
Note:Test Conditions : 23℃, 50%RH, 24 hours.The data sheet is for your reference. And the data above will vary as the actual using condition changes.

Applications

Skate bracket, Baby stroller accessories, Sports equipment.
