PA6/66
Glass Fiber Reinforced / Impact Modified
Glass fiber reinforced nylon for enhanced strength, stiffness and low temperature impact resistance.
C2201GT30BKE1
Material：
PA6/66
Specification：
Impact resistant 30% glass fiber reinforced
Color：
Black
Certification：
RoHS、REACH、GRS(Global Recycle Standard)
Package：
25kg
Property：
High stiffness, toughness and low temperature impact resistance, suitable for fabrication
1. 物性標準 Materials Standard：
| 檢測項目 | Property |
測試方法 Test Method |
單位 Unit |
數值 Vaule |
|---|---|---|---|---|
| 機械性質 | Mechanical Properties | |||
| 抗張強度 | Tensile Strength | ASTM D638 | Kg/cm2 | 1300 |
| 延伸率 | Elongation at Break | ASTM D638 | % | < 5 |
| 彎曲強度 | Flexural Strength | ASTM D790 | kg/cm2 | 2050 |
| 彎曲彈性模數 | Flexural Modulus | ASTM D790 | kg/cm2 | 70000 |
| 衝擊強度 |
IZOD Impact, Notched 1/8" 23°C IZOD Impact, Notched 1/8" -30°C |
ASTM D256 | kg-cm/cm |
16 |
| 硬度 |
Hardness Shore D Hardness Rockwell R Scale |
ASTM D2240 ASTM D785 |
- |
120 |
| 熱特性 | Thermal | |||
| 熱變形溫度 |
Heat Deflection Temperature (18.6kg/cm2 ) |
ASTM D648 | °C | 245 |
| 其它 | Other | |||
| 收縮率 | Shrinkage | ASTM D955 | % | 0.3~0.8 |
| 熔融指數 | Melt Index | ASTM D1238 | g/10min | - |
| 比重 | Specific Gravity | ASTM D792 | - | 1.33 |
| 灰份 | Ash Content | ASTM D482 | % | 30 |
| 含水率 | Equilibrium Moisture Content | ASTM D570 | % | < 0.3 |
| 耐燃性 | Flammability | UL 94 | 1.6mm | - |
2.成形條件 Molding Condition：
| 乾燥條件 Drying | 料管溫度 Melt Temp | 射出壓力 Inject Press. |
|---|---|---|
| 80~100°C*4HR | 245~280°C | 20kg/cm2 |
附註:測試條件: 23℃, 50%RH, 24小時。以上數據會隨使用條件不同而有所改變，故此數據僅供參考。
Note:Test Conditions : 23℃, 50%RH, 24 hours.The data sheet is for your reference. And the data above will vary as the actual using condition changes.
