PA66
Ultra Impact Modified Grade
Increase the toughness of nylon at low temperatures.
B2000TSDA3
Material：
PA66
Specification：
Low Temperature Impact Resistance
Color：
Natural color, providing custom dyeing service
Certification：
RoHS、REACH
Package：
25kg
Property：
Excellent ultra high toughness, low temperature impact resistance and surface improved
1. 物性標準 Materials Standard：
| 檢測項目 | Property |
測試方法 Test Method |
單位 Unit |
數值 Vaule |
|---|---|---|---|---|
| 機械性質 | Mechanical Properties | |||
| 抗張強度 | Tensile Strength | ASTM D638 | Kg/cm2 | 450 |
| 延伸率 | Elongation at Break | ASTM D638 | % | > 70 |
| 彎曲強度 | Flexural Strength | ASTM D790 | kg/cm2 | 700 |
| 彎曲彈性模數 | Flexural Modulus | ASTM D790 | kg/cm2 | 18000 |
| 衝擊強度 |
IZOD Impact, Notched 1/8" 23°C IZOD Impact, Notched 1/8" -30°C |
ASTM D256 | kg-cm/cm |
> 85 20 |
| 硬度 |
Hardness Shore D Hardness Rockwell R Scale |
ASTM D2240 ASTM D785 |
- |
80 |
| 熱特性 | Thermal | |||
| 熱變形溫度 |
Heat Deflection Temperature (18.6kg/cm2 ) |
ASTM D648 | °C | 50 |
| 其它 | Other | |||
| 收縮率 | Shrinkage | ASTM D955 | % | 1.6~2.0 |
| 熔融指數 | Melt Index | ASTM D1238 | g/10min | > 5 |
| 比重 | Specific Gravity | ASTM D792 | - | 1.07 |
| 灰份 | Ash Content | ASTM D482 | % | - |
| 含水率 | Equilibrium Moisture Content | ASTM D570 | % | < 0.3 |
| 耐燃性 | Flammability | UL 94 | 1.6mm | - |
2.成形條件 Molding Condition：
| 乾燥條件 Drying | 料管溫度 Melt Temp | 射出壓力 Inject Press. |
|---|---|---|
| 80~100°C*4HR | 245~280°C | 20kg/cm2 |
附註:測試條件: 23℃, 50%RH, 24小時。以上數據會隨使用條件不同而有所改變，故此數據僅供參考。
Note:Test Conditions : 23℃, 50%RH, 24 hours.The data sheet is for your reference. And the data above will vary as the actual using condition changes.
B6000TBKA3
Material：
PA66
Specification：
Low Temperature Impact Resistance
Color：
Black
Certification：
RoHS、REACH、GRS(Global Recycle Standard)
Package：
25kg
Property：
Excellent ultra high toughness, low temperature impact resistance and surface improved
1. 物性標準 Materials Standard：
| 檢測項目 | Property |
測試方法 Test Method |
單位 Unit |
數值 Vaule |
|---|---|---|---|---|
| 機械性質 | Mechanical Properties | |||
| 抗張強度 | Tensile Strength | ASTM D638 | Kg/cm2 | 450 |
| 延伸率 | Elongation at Break | ASTM D638 | % | > 70 |
| 彎曲強度 | Flexural Strength | ASTM D790 | kg/cm2 | 800 |
| 彎曲彈性模數 | Flexural Modulus | ASTM D790 | kg/cm2 | 17500 |
| 衝擊強度 |
IZOD Impact, Notched 1/8" 23°C IZOD Impact, Notched 1/8" -30°C |
ASTM D256 | kg-cm/cm |
> 80 16 |
| 硬度 |
Hardness Shore D Hardness Rockwell R Scale |
ASTM D2240 ASTM D785 |
- |
72 |
| 熱特性 | Thermal | |||
| 熱變形溫度 |
Heat Deflection Temperature (18.6kg/cm2 ) |
ASTM D648 | °C | 50 |
| 其它 | Other | |||
| 收縮率 | Shrinkage | ASTM D955 | % | 1.6~2.0 |
| 熔融指數 | Melt Index | ASTM D1238 | g/10min | > 10 |
| 比重 | Specific Gravity | ASTM D792 | - | 1.07 |
| 灰份 | Ash Content | ASTM D482 | % | - |
| 含水率 | Equilibrium Moisture Content | ASTM D570 | % | < 0.3 |
| 耐燃性 | Flammability | UL 94 | 1.6mm | - |
2.成形條件 Molding Condition：
| 乾燥條件 Drying | 料管溫度 Melt Temp | 射出壓力 Inject Press. |
|---|---|---|
| 80~100°C*4HR | 245~280°C | 20kg/cm2 |
附註:測試條件: 23℃, 50%RH, 24小時。以上數據會隨使用條件不同而有所改變，故此數據僅供參考。
Note:Test Conditions : 23℃, 50%RH, 24 hours.The data sheet is for your reference. And the data above will vary as the actual using condition changes.
