PA66

PA66

General Grade

Raw materials without adding any reinforcements.

B2030NC

Material Material：

PA66

Specification Specification：

General Grade

Color Color：

Natural color, providing custom dyeing service

Certification Certification：

RoHS、REACH、GRS(Global Recycle Standard)

Package Package：

25kg

Property Property：

Low viscosity, the appearance is translucent

B2030NC Add to Inquriy Cart Download

1. 物性標準 Materials Standard：

檢測項目 Property 測試方法
Test Method 		單位
Unit 		數值
Vaule
機械性質 Mechanical Properties
抗張強度 Tensile Strength ASTM D638 Kg/cm2 780
延伸率 Elongation at Break ASTM D638 % > 10
彎曲強度 Flexural Strength ASTM D790 kg/cm2 1300
彎曲彈性模數 Flexural Modulus ASTM D790 kg/cm2 30000
衝擊強度 IZOD Impact, Notched 1/8" 23°C
IZOD Impact, Notched 1/8" -30°C 		ASTM D256 kg-cm/cm 6
硬度 Hardness Shore D
Hardness Rockwell R Scale 		ASTM D2240
ASTM D785 		- 80
熱特性 Thermal
熱變形溫度 Heat Deflection Temperature
(18.6kg/cm2 ) 		ASTM D648 °C 85
其它 Other
收縮率 Shrinkage ASTM D955 % 1.2~1.6
熔融指數 Melt Index ASTM D1238 g/10min 90~120
比重 Specific Gravity ASTM D792 - 1.14
灰份 Ash Content ASTM D482 % < 1
含水率 Equilibrium Moisture Content ASTM D570 % < 0.3
耐燃性 Flammability UL 94 1.6mm -

2.成形條件 Molding Condition：

乾燥條件 Drying 料管溫度 Melt Temp 射出壓力 Inject Press.
80~100°C*4HR 245~280°C 20kg/cm2

附註:測試條件: 23℃, 50%RH, 24小時。以上數據會隨使用條件不同而有所改變，故此數據僅供參考。
Note:Test Conditions : 23℃, 50%RH, 24 hours.The data sheet is for your reference. And the data above will vary as the actual using condition changes.

Applications

Washer, Baby Strollers, Electrical and electronic parts, Information technology equipment parts, Tool housing , Sports equipment, Gear, Automobiles parts.

B2030SD

Material Material：

PA66

Specification Specification：

General Grade

Color Color：

White, providing custom dyeing services

Certification Certification：

RoHS、REACH、GRS(Global Recycle Standard)

Package Package：

25kg

Property Property：

Low viscosity, the appearance is white

B2030SD Add to Inquriy Cart Download

1. 物性標準 Materials Standard：

檢測項目 Property 測試方法
Test Method 		單位
Unit 		數值
Vaule
機械性質 Mechanical Properties
抗張強度 Tensile Strength ASTM D638 Kg/cm2 730
延伸率 Elongation at Break ASTM D638 % > 10
彎曲強度 Flexural Strength ASTM D790 kg/cm2 1200
彎曲彈性模數 Flexural Modulus ASTM D790 kg/cm2 29000
衝擊強度 IZOD Impact, Notched 1/8" 23°C
IZOD Impact, Notched 1/8" -30°C 		ASTM D256 kg-cm/cm 5
硬度 Hardness Shore D
Hardness Rockwell R Scale 		ASTM D2240
ASTM D785 		- 80
熱特性 Thermal
熱變形溫度 Heat Deflection Temperature
(18.6kg/cm2 ) 		ASTM D648 °C 85
其它 Other
收縮率 Shrinkage ASTM D955 % 1.2~1.6
熔融指數 Melt Index ASTM D1238 g/10min 70~250
比重 Specific Gravity ASTM D792 - 1.14
灰份 Ash Content ASTM D482 % < 1
含水率 Equilibrium Moisture Content ASTM D570 % < 0.3
耐燃性 Flammability UL 94 1.6mm -

2.成形條件 Molding Condition：

乾燥條件 Drying 料管溫度 Melt Temp 射出壓力 Inject Press.
80~100°C*4HR 245~280°C 20kg/cm2

附註:測試條件: 23℃, 50%RH, 24小時。以上數據會隨使用條件不同而有所改變，故此數據僅供參考。
Note:Test Conditions : 23℃, 50%RH, 24 hours.The data sheet is for your reference. And the data above will vary as the actual using condition changes.

Applications

Washer, Baby Strollers, Electrical and electronic parts, Information technology equipment parts, Tool housing , Sports equipment, Gear, Automobiles parts.

B2040BK

Material Material：

PA66

Specification Specification：

General Grade

Color Color：

Black

Certification Certification：

RoHS、REACH、GRS(Global Recycle Standard)

Package Package：

25kg

Property Property：

Low viscosity, can be used for the molding of finish molds

B2040BK Add to Inquriy Cart Download

1. 物性標準 Materials Standard：

檢測項目 Property 測試方法
Test Method 		單位
Unit 		數值
Vaule
機械性質 Mechanical Properties
抗張強度 Tensile Strength ASTM D638 Kg/cm2 680
延伸率 Elongation at Break ASTM D638 % > 2
彎曲強度 Flexural Strength ASTM D790 kg/cm2 1200
彎曲彈性模數 Flexural Modulus ASTM D790 kg/cm2 28500
衝擊強度 IZOD Impact, Notched 1/8" 23°C
IZOD Impact, Notched 1/8" -30°C 		ASTM D256 kg-cm/cm 5
硬度 Hardness Shore D
Hardness Rockwell R Scale 		ASTM D2240
ASTM D785 		- 80
熱特性 Thermal
熱變形溫度 Heat Deflection Temperature
(18.6kg/cm2 ) 		ASTM D648 °C 85
其它 Other
收縮率 Shrinkage ASTM D955 % 1.2~1.6
熔融指數 Melt Index ASTM D1238 g/10min 70~250
比重 Specific Gravity ASTM D792 - 1.14
灰份 Ash Content ASTM D482 % < 2
含水率 Equilibrium Moisture Content ASTM D570 % < 0.3
耐燃性 Flammability UL 94 1.6mm -

2.成形條件 Molding Condition：

乾燥條件 Drying 料管溫度 Melt Temp 射出壓力 Inject Press.
80~100°C*4HR 245~280°C 20kg/cm2

附註:測試條件: 23℃, 50%RH, 24小時。以上數據會隨使用條件不同而有所改變，故此數據僅供參考。
Note:Test Conditions : 23℃, 50%RH, 24 hours.The data sheet is for your reference. And the data above will vary as the actual using condition changes.

Applications

Sporting Goods - Glasses Temples
Washer, Baby Strollers, Electrical and electronic parts, Information technology equipment parts, Tool housing , Sports equipment, Gear, Automobiles parts.

B4040BK

Material Material：

PA66

Specification Specification：

General Grade

Color Color：

Black

Certification Certification：

RoHS、REACH

Package Package：

25kg

Property Property：

Low viscosity, can be used for the molding of texture molds

B4040BK Add to Inquriy Cart Download

1. 物性標準 Materials Standard：

檢測項目 Property 測試方法
Test Method 		單位
Unit 		數值
Vaule
機械性質 Mechanical Properties
抗張強度 Tensile Strength ASTM D638 Kg/cm2 600
延伸率 Elongation at Break ASTM D638 % > 2
彎曲強度 Flexural Strength ASTM D790 kg/cm2 1100
彎曲彈性模數 Flexural Modulus ASTM D790 kg/cm2 25000
衝擊強度 IZOD Impact, Notched 1/8" 23°C
IZOD Impact, Notched 1/8" -30°C 		ASTM D256 kg-cm/cm 4
硬度 Hardness Shore D
Hardness Rockwell R Scale 		ASTM D2240
ASTM D785 		- 80
熱特性 Thermal
熱變形溫度 Heat Deflection Temperature
(18.6kg/cm2 ) 		ASTM D648 °C 85
其它 Other
收縮率 Shrinkage ASTM D955 % 1.2~1.6
熔融指數 Melt Index ASTM D1238 g/10min > 150
比重 Specific Gravity ASTM D792 - 1.15
灰份 Ash Content ASTM D482 % < 5
含水率 Equilibrium Moisture Content ASTM D570 % < 0.3
耐燃性 Flammability UL 94 1.6mm -

2.成形條件 Molding Condition：

乾燥條件 Drying 料管溫度 Melt Temp 射出壓力 Inject Press.
80~100°C*4HR 245~280°C 20kg/cm2

附註:測試條件: 23℃, 50%RH, 24小時。以上數據會隨使用條件不同而有所改變，故此數據僅供參考。
Note:Test Conditions : 23℃, 50%RH, 24 hours.The data sheet is for your reference. And the data above will vary as the actual using condition changes.

Applications

Washer, Baby Strollers, Electrical and electronic parts, Information technology equipment parts, Tool housing , Sports equipment, Gear, Automobiles parts.
